AC18060

AC Fan

AC18060

, 180x180x60mm

Dimensions Drawing

INQUIRY NOW

Technical Parameters

Listed Model	Bearing System	Rated Voltage	Freq.	Current	Input Watt	Speed	Air Flow		Static Pressure		Noise	Weight
Listed Model	Bearing System	VAC	Hz	A	Watt	RPM	CFM	m³/min	mmH₂O	InchH₂O	dBA	g
X18060A1HB	Ball	110	50/60	0.69	56	2600	280	7.95	13.18	0.51	59	1600
X18060A2HB	Ball	220	50/60	0.30	45	2600	280	7.95	13.18	0.51	59	1600
X18060A3HB	Ball	380	50/60	0.16	42	2550	275	7.81	13.10	0.50	59	1600

Notes:

All readings are typical values at rated voltage. Specifications subjected to change without prior notice. If you need to speed or voltage function not on the list, Please contact us.
